Blackmagic Design: supported models


Our software uses a native Decklink SDK to work with its devices. Please make sure that you've installed required components of the SDK to work with devices and that drivers are updated to the newest version.


The main features that are implemented:
  • Input SDI/HDMI/component/composite signals
  • Output SDI/HDMI/component/composite signals
  • Internal and external keying
  • Fill-only and Key-only outputs
  • Closed Captioning (CEA-608, EIA-708, Line21)
  • Bypass relays (for Decklink Quad only)
  • VANC data processing
  • Timecode support

Note. BMD supports only YUV (8- and 10-bit) formats for NTSC and PAL modes.


Tested devices

The latest recommended drivers are  11.4.1 .

Here is a list of Blackmagic Design devices that we've tested in our labs:


Device

SD

HD

4K_UHD_30p

CC

Keying

DeckLink SDI 4K








DeckLink

4K Extreme 12G






DeckLink Studio 2



up to 30p




DeckLink Studio 4K






DeckLink Quad 1



up to 30p




DeckLink

Mini Monitor



up to 30p




Intensity Pro 4K






DeckLink

Mini Recorder



up to 30p




DeckLink

Quad HDMI Recorder






DeckLink 8K Pro






DeckLink Quad 2
